Description
Description
High efficiency, Iron powder electrode designed for outstanding deposition rates. Deposition efficiency is approximately 140—150 % .Excellent arc stability, soft fusion, fine ripples, self releasing slag, very low spatter. Applied for heavy steel structures, storage tanks, bridge girders, fabrication of earth moving equipments, pressure vessels etc. Frequently used for butt-welding plates with a heavy thickness and for fillet welds.
Rutile type heavy coated, iron powder electrode with a deposition efficiency of 165% approx. It is designed for butt and fillet welds, used to large weld sections and making long fillet welds. Excellent arc stability, soft fusion, fine ripples, self releasing slag, very low spatter. Easy arc striking and re-striking.
TechnicaL Specification
| PRODUCT NAME | AWS/SFA | YIELDSTRENGTH N/MM2 | TENSILE STRENGTHN/MM2 | ELONGATIONA5(%) | CHARPY IMPACT VALUE ISO-V J +20°C | PRODUCT NAME | AWS/SFA | YIELDSTRENGTH N/MM2 | TENSILE STRENGTHN/MM2 | ELONGATIONA5(%) | CHARPY IMPACT VALUE ISO-V J +20°C |
| SUPER OPTIMAL 7024 | E 7024 | ≥400 | 510-600 | ≥24 | ≥64 | SUPER OPTIMAL 7024 S | E 7024 | ≥400 | 510-600 | ≥24 | ≥60 |
