Description
| Features: |
|
|---|---|
| Classification: | AWS A5.11 ENiCrFe-9 |
| Redrying Conditions: | 200-250°Cx0.5-1h |
| Identification color: | 1st Silver grey, 2nd Pink |
| Polarity: | AC |
Packaging data
| φ mm | Length mm | kg/pack | kg/carton | g/piece | carton mm |
|---|---|---|---|---|---|
| 3.2 | 300 | 2 | 20 | 29 | 300W, 100H, 330L |
| 4.0 | 350 | 5 | 20 | 53 | 175W, 130H, 380L |
| 5.0 | 350 | 5 | 20 | 82 | 175W, 130H, 380L |
Composition (all-weld metal mass %)
| Typical | Guarantya | |
|---|---|---|
| C | 0.08 | 0.15 |
| Si | 0.26 | 0.75 |
| Mn | 2.4 | 1.0-4.5 |
| P | 0.01 | 0.02 |
| S | <0.01 | 0.015 |
| Ni | 66.6 | 55.0min. |
| Cr | 13.8 | 12.0-17.0 |
| Mo | 3.9 | 2.5-5.5 |
| Cu | 0.02 | 0.50 |
| Nb+Ta | 1.5 | 0.5-3.0 |
| Fe | 10.3 | 12.00 |
| W | 0.6 | 1.5 |
| Note: aSingle values are maximium. | ||
Welding parameters (A)
| φ mm | 1F, 1G, 2F, 2G | 3G uphill, 4G |
|---|---|---|
| 3.2 | 70-115 | 65-110 |
| 4.0 | 95-145 | 85-135 |
| 5.0 | 115-180 | - |
All-weld mechanical properties
| Typical | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 450 | - |
| TS (MPa) | 703 | 655min. |
| EI on 4d (%) | 43 | 25min. |
| IV -196°C (J) | 63 | - |
Approvals / Click here for certificates
| ABS | MG(AWS A5.11 ENiCrFe-9) |
|---|---|
| LR | 5Nim,9Nim |
| DNV | MG(VL9Ni),H10 |
| BV | UP(ENiCrFe-9) |
| NK | KMWL92 |
| CCS | 9Ni |
| KR | L91 |
| Note: AC | |
