Description
| Features: |
|
|---|---|
| Classification: | AWS A5.11 ENiMo-8 |
| Redrying Conditions: | 200-250°Cx0.5-1h |
| Identification color: | 1st Yellow, 2nd Green |
| Polarity: | AC |
Packaging data
| φ mm | Length mm | kg/pack | kg/carton | g/piece | carton mm |
|---|---|---|---|---|---|
| 3.2 | 300 | 2 | 20 | 30 | 300W, 100H, 330L |
| 4.0 | 350 | 5 | 20 | 55 | 175W, 130H, 380L |
| 5.0 | 350 | 5 | 20 | 84 | 175W, 130H, 380L |
Composition (all-weld metal mass %)
| Typical | Guarantya | |
|---|---|---|
| C | 0.02 | 0.10 |
| Si | 0.47 | 0.75 |
| Mn | 0.3 | 1.5 |
| P | <0.01 | 0.02 |
| S | 0.001 | 0.015 |
| Ni | 68.7 | 60.0min. |
| Cr | 1.8 | 0.5-3.5 |
| Mo | 18.4 | 17.0-20.0 |
| Cu | 0.01 | 0.50 |
| Fe | 7.0 | 10.0 |
| W | 2.9 | 2.0-4.0 |
| Note: aSingle values are maximium. | ||
Welding parameters (A)
| φ mm | 1F, 1G, 2F, 2G | 3G uphill, 4G |
|---|---|---|
| 3.2 | 70-115 | 65-110 |
| 4.0 | 100-145 | 85-135 |
| 5.0 | 130-200 | - |
All-weld mechanical properties
| Typical | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 473 | - |
| TS (MPa) | 750 | 655min. |
| EI on 4d (%) | 46 | 25min. |
| IV -196°C (J) | 92 | - |
Approvals / Click here for certificates
| NK | KMWL92,KMWL92-YP420M-TS690M |
|---|---|
| Note: AC | |
