Description
| Features: |
|
|---|---|
| Classification: | AWS A5.1 E7018-1 |
| Redrying Conditions: | 350-400°Cx1h |
| Identification color: | 1st Brown, 2nd White |
| Polarity: | AC, DCEP |
Packaging data
| φ mm | Length mm | kg/pack | kg/carton | g/piece | carton mm |
|---|---|---|---|---|---|
| 2.6 | 350 | 5 | 20 | 23 | 170W, 105H, 380L |
| 3.2 | 350 | 5 | 20 | 35 | 170W, 105H, 380L |
| 4.0 | 400 | 5 | 20 | 61 | 170W, 105H, 430L |
| 4.0 | 450 | 5 | 20 | 69 |
170W, 100H, 480L |
| 5.0 | 450 | 5 | 20 | 106 | 170W, 110H, 480L |
Composition (all-weld metal mass %)
| Typical (DCEP) | Guarantya | |
|---|---|---|
| C | 0.08 | 0.15 |
| Si | 0.37 | 0.75 |
| Mn | 1.53 | 1.60 |
| P | 0.012 | 0.035 |
| S | 0.003 | 0.035 |
| Ni | 0.01 | 0.30 |
| Cr | 0.03 | 0.20 |
| Mo | 0.01 | 0.30 |
| V | <0.01 | 0.08 |
| Ti | 0.025 | - |
| B | 0.0045 | - |
| Others b | 1.58 | 1.75 |
| Note: aSingle values are maximium. bCombined Limit for Mn+Ni+Cr+Mo+V |
||
Welding parameters (A)
| φ mm | 1F, 1G, 2F, 2G | 3G uphill, 4G |
|---|---|---|
| 2.6 | 70-100 | 65-95 |
| 3.2 | 90-130 | 80-120 |
| 4.0 | 130-180 | 110-170 |
| 5.0 | 180-240 | - |
All-weld mechanical properties
| Typical (DCEP) | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 490 | 400min. |
| TS (MPa) | 580 | 483min. |
| EI on 4d (%) | 31 | 22min. |
| IV -46°C (J) | 135 | 27min. |
Approvals / Click here for certificates
| ABS | 4Y400, H10 |
|---|---|
| LR | 4Y40m H10 |
