Description
| Features: |
|
|---|---|
| Classification: | AWS A5.14 ERNiMo-8 |
| Shielding gas: | Ar |
| Identification color: | 1st Orange |
| Polarity: | DCEN |
Packaging data
| Spool | Tube | |||||
|---|---|---|---|---|---|---|
| φ mm | kg | kg | Length mm | g/piece | ||
| 1.2 | 10 | 15 | 20 | 5 | 1,000 | 11 |
| 1.6 | 10 | 15 | - | 5 | 1,000 | 19 |
| 2.0 | - | - | - | 5 | 1,000 | 29 |
| 2.4 | - | - | - | 5 | 1,000 | 42 |
| Volume mm | 240W, 110H, 240L | 285W, 110H, 285L | 40W, 35H, 1015L | |||
Composition (rod and wire mass%)
| Typical | Guarantya | |
|---|---|---|
| C | 0.02 | 0.10 |
| Si | 0.02 | 0.50 |
| Mn | <0.1 | 1.0 |
| P | 0.001 | 0.015 |
| S | 0.001 | 0.015 |
| Ni | 69.8 | 60.0min. |
| Cr | 2.0 | 0.5-3.5 |
| Mo | 19.1 | 18.0-21.0 |
| W | 3.0 | 2.0-4.0 |
| Fe | 5.6 | 10.0 |
| Cu | 0.01 | 0.50 |
| Note: aSingle values are maximium. | ||
All-weld mechanical properties
| Typical | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 460 | - |
| TS (MPa) | 730 | 660min. |
| EI on 4d (%) | 47 | 25min. |
| IV -196°C (J) | 160 | - |
Approvals / Click here for certificates
| ABS | MG(AWS A5.14 ERNiMo-8) |
|---|---|
| LR | 9Nim |
| DNV | MS(9Ni) |
| BV | Equivalent to AWS A5.14 ERNiMo-8 |
| NK | KSWL92G(I) |
