Description
| Features: |
|
|---|---|
| Classification: | AWS - |
| Shielding gas: | Ar |
| Identification color: | - |
| Polarity: | DCEN |
Packaging data
| Spool | Tube | |||
|---|---|---|---|---|
| φ mm | kg | kg | Length mm | g/piece |
| 1.0 | 10 | 5 | 1,000 | 6 |
| 1.2 | 10 | 5 | 1,000 |
9 |
| 1.6 | 10 | 5 | 1,000 | 16 |
| 2.0 | - | 5 | 1,000 | 25 |
| 2.4 | - | 5 | 1,000 | 36 |
| Volume mm | 240W, 110H, 240L | 40W, 35H, 1015L | ||
Composition (rod and wire mass%)
| Typical | Guarantya | |
|---|---|---|
| C | 0.005 | 0.045 |
| Si | 0.16 | 1.00 |
| Mn | 6.10 | 4.00-7.00 |
| P | 0.011 | 0.030 |
| S | 0.004 | 0.020 |
| Ni | 16.29 | 14.00-18.00 |
| Cr | 18.24 | 17.00-19.50 |
| Mo | 2.56 | 2.20-3.00 |
| N | 0.01 | 0.20 |
| Note: aSingle values are maximium. | ||
Welding parameters (A)
| φ mm | |
|---|---|
| 1.0 | 50-80 |
| 1.2 | 50-100 |
| 1.6 | 100-200 |
| 2.0 | 100-200 |
| 2.4 | 150-250 |
All-weld mechanical properties
| Typical | |
|---|---|
| 0.2%YS (MPa) | 360 |
| TS (MPa) | 490 |
| EI on 4d (%) | 41 |
| IV -257°C (J) | 99 |
