HONAVAR;FILLER WIRE; AWS A 5.28 ER 80S; ER 80S-B2

BRAND : ER 80S-B2

AWS A 5.28 ER 80S

Applications:

For creep-resistant ICr- 1⁄2 Mo Steel in boilers, pipelines, chemical petrochemical industry especially when handling sulphurous produ

1000 mm length in sizes: 1.6 mm, 2.0 mm, 2.40 mm, 3.2 mm.

Materials to be welded:

ASTM A 199, A 200, A 213, Grades T11 & T12 ASTM A 335 Grades P 11 & P 12

Cast Steel A 217 WC 6, WC 11.

CHEMICAL ANALYSIS (Typical) %

C	0.08	Al	< 0.020
Mo	0.55	S	< 0.020
Mn	0.60	V	<0.030
Ni	<0.20	Cr	1.30
Si	0.55	Nb	<0.010
Cu	<0.30	P	<0.020

BRUSCATO-X-FACTOR < 15 PPM   All Weld Mechanical Properties (After PWHT) (Typical Values)

UTS	620 MPa	CVN Impact Energy
YS	510 MPa	At +20°C	120 Joules
Elongation	24.0%	At-10°C	100 Joules

CHEMICAL ANALYSIS (%) OF WIRE IN STOCK:

c	0.081	P	0.009	V	0.005	Cu	0.16
Mn	0.58	Cr	1.24	Mo	0.42	Ni	0.085
Si	0.47	S	0.009	Sn	0.008	As	0.002
				Sb	0.003
