HONAVAR;FILLER WIRE; AWS A5.9 ER 308L; HW-308L

BRAND : HONAVAR MIG/TIG ROD HW-308L An Extra Low Carbon Stainless Steel Rod Of 18/8 Type For MIG/TIG Welding.

Classification:

AWS A5.9 ER 308L

DIN-8556: X2 Cr. Ni 19.9

DESCRIPTION:

Honavar MIG/TIG Rod HW 308L is 18 Cr. 8Ni type rod for GTAW austenitic corrosion resistant steels HW-308L TIG ROD is suitable for welding of AISI-301, 304, 304L and equivalent grade. Also provides acceptable results on niobium and titanium stabilized stcels.

TYPICAL WIRE COMPOSITION (%):

C	Mn	Si	Cr	Ni	S	P
0.025	1.5	0.4	20	10	0.018	0.018

  TYPICAL ALL WELD METAL PROPERTIES:

Weldmetal	Composition (%)	Mechanical Properties
C : 0.025	Cr. 20.0	YS : 450 N/mm²
Mn : 1.6	Ni 10.0	UTS: 645 N/mm²
Si : 0.4	P : 0.018	EL (L=4d) 36%
S : 0.018		Impact (CVN) at - -196°C-70J

  PACKING DATA:

Size	Length (mm)
1.6	1000
2.0	1000
2.5	1000

Packing 10 Kg. & also available in spool of 12.5 kg.
