Description
| Features: |
|
|---|---|
| Classification: | AWS A5.1 E7016 |
| Redrying Conditions: | 300-350°Cx0.5-1h |
| Identification color: | 1st Blue white, 2nd Pink |
| Polarity: | AC, DCEP |
Packaging data
| φ mm | Length mm | kg/pack | kg/carton | g/piece | carton mm |
|---|---|---|---|---|---|
| 2.6 | 350 | 5 | 20 | 20 | 170W, 110H, 380L |
| 3.2 | 400 | 5 | 20 | 35 | 170W, 110H, 430L |
| 4.0 | 400 | 5 | 20 | 53 | 170W, 110H, 430L |
Composition (all-weld metal mass %)
| Typical (AC) | Guarantya | |
|---|---|---|
| C | 0.08 | 0.15 |
| Si | 0.64 | 0.75 |
| Mn | 0.86 | 1.60 |
| P | 0.012 | 0.035 |
| S | 0.008 | 0.035 |
| Ni | 0.01 |
0.30 |
| Cr | 0.02 | 0.20 |
| Mo | <0.01 | 0.30 |
| V | 0.01 | 0.08 |
| Othersb | 0.90 | 1.75 |
| Note: aSingle values are maximium. bCombined Limit for Mn+Ni+Cr+Mo+V |
||
Welding parameters (A)
| φ mm | 1F, 1G, 2F, 2G | 3G uphill, 4G | Root passc |
|---|---|---|---|
| 2.6 | 60-90 | 50-80 | 30-80 |
| 3.2 | 90-130 | 80-120 | 60-110 |
| 4.0 | 130-180 | 110-170 | 90-140 |
| Note: cDCEN is also suitable. | |||
All-weld mechanical properties
| Typical (AC) | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 480 | 400min. |
| TS (MPa) | 560 | 483min. |
| EI on 4d (%) | 31 | 22min. |
| IV -29°C (J) | 80 | 27min. |
Approvals / Click here for certificates
| ABS | 3Y, MG, H10 |
|---|---|
| LR | 3Ym,MG,H15 |
| DNV | 3Y, H10 |
| BV | 3YH10 |
| NK a) | KMW53, H10 |
| CCS |
3Y, H10 |
| NAKS | AWS A5.1 E7016 |
| a):AC | |
