Description
| Features: |
|
|---|---|
| Classification: | AWS - |
| Redrying Conditions: | 70-100°Cx0.5-1h |
| Identification color: | 1st Purple, 2nd Orange |
| Polarity: | AC, DCEP, DCEN |
Packaging data
| φ mm | Length mm | kg/pack | kg/carton | g/piece | carton mm |
|---|---|---|---|---|---|
| 4.0 | 450 | 5 | 20 | 76 | 170W, 90H, 480L |
| 4.5 | 500, 700 | 5 | 20 | 138, 175 | 170W, 60-75H, 580-730L |
| 5.0 | 450, 550, 700 | 5, 10 | 20 | 130, 159, 203 | 170W, 60-95H, 480-730L |
| 5.5 | 450, 550, 700 | 5, 10 | 20 | 153, 187, 239 | 170W, 65-95H, 480-730L |
| 6.0 | 450, 550, 700 | 5, 10 | 20 | 176, 215, 273 | 170W, 65-95H, 480-730L |
| 6.4 | 450, 550, 700 | 5, 10 | 20 | 189, 231, 294 |
170W, 60-95H, 480-730L |
| 7.0 | 700 | 10 | 20 | 350 | 170W, 60H, 730L |
Composition (all-weld metal mass %)
| Typical (AC) | Guarantya | |
|---|---|---|
| C | 0.07 | 0.13 |
| Si | 0.39 | 0.10-0.70 |
| Mn | 0.94 | 0.60-1.25 |
| P | 0.017 | 0.030 |
| S | 0.009 | 0.025 |
| Ni | 0.01 | 0.30 |
| Cr | 0.02 | 0.20 |
| Mo | <0.01 | 0.30 |
| V | 0.01 | 0.08 |
| Note: aSingle values are maximium. | ||
Welding parameters (A)
| φ mm | 1F, 2F |
|---|---|
| 4.0 | 135-195 |
| 4.5 | 170-220 |
| 5.0 | 200-240 |
| 5.5 | 230-280 |
| 6.0 | 260-310 |
| 6.4 | 280-330 |
| 7.0 | 300-350 |
All-weld mechanical properties
| Typical (AC) | Guaranty | |
|---|---|---|
| 0.2%YS (MPa) | 480 | 390min. |
| TS (MPa) | 530 | 490min. |
| EI on 4d (%) | 29 | 16min. |
| IV 0°C (J) | 74 | 47min. |
Approvals / Click here for certificates
| ABS | 3,3Y |
|---|---|
| LR | 3Ym, 3YG |
| DNV | 3Y, MG |
| BV | 3Y |
| NK | KMW53 |
| CR | 3Y |
