Description
| Specification | PL-S1500W | PL-S2000W |
| Rated Output Power | 1500W | 2000W |
| Rated Output Power | 1500W ±2% | 2000W ±2% |
| Rated Output Power | Continuous Fiber Laser | Continuous Fiber Laser |
| Laser Wavelength | 1070 nm | 1070 nm |
| FM | 0~5 kHz | 0~5 kHz |
| Spot Diameter | 5~7 mm | 5~7 mm |
| Welding Speed Range | 1~120 mm/s | 1~120 mm/s |
| Welding Gap Requirements | ≤0.5 mm | ≤0.5 mm |
| Wire Width | ≤5 mm | ≤5 mm |
| Rated Output Power | 1500W | 2000W |
| Welding Thickness - Stainless Steel | ≤4 mm | ≤5 mm |
| Welding Thickness - Carbon Steel | <2.5 mm | <3.5 mm |
| Welding Thickness - Aluminum | <2 mm | <3 mm |
| Beam Quality | M²<1.2 | M²<1.2 |
| Output Fiber Length | Standard 10 m / Customizable Lengthening | |
| Fiber Bending Radius | 100 mm | 100 mm |
| Way of Working | Continuous CW / Modulation | |
| Working Environment Temperature Range | 15~35°C/ <70% without condensation | |
| Weld Head Operating Mode | Normal / Hand-Held Swing Welding Mode | |
| Power Consumption of Whole Machine | 9 KW | 12 KW |
| Cooling Mode | Built-in chiller | Built-in chiller |
| Power Requirements | Three-phase AC380V±10%/50Hz/40A | Three-phase AC380V±10%/50Hz/40A |
